fully wrapped carbon fiber cylinder/ 6.8L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder
fully wrapped carbon fiber cylinder/ 6.8L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder fully wrapped carbon fiber cylinder/ 6.8L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder fully wrapped carbon fiber cylinder/ 6.8L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder
fully wrapped carbon fiber cylinder/ 6.8L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder fully wrapped carbon fiber cylinder/ 6.8L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder fully wrapped carbon fiber cylinder/ 6.8L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder
Name:fully wrapped carbon fiber cylinder/ 6.8L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder
Water volume:0.5L-12L
Outer diameter:85mm-208mm
Working pressure:300bar
Test pressure:500bar
Cylinder life-span:15years
Material:Aluminium lined and carbon fiber fully wrapped
Certificate:CE
Standard:EN1225
MOQ:15PCS
Terms of Payment:T/T,L/C or Western Union
Delivery Time:20 days after payment
Port of Lading:Shanghai or Ningbo

Product Description


Type

Volume

litre)

Outer Diameter

(mm)

Length

(mm)

Weight

(kg)

Working Pressure

(Mpa)

Breaking Pressure

(Mpa)

HFCFC-0.5

0.5

60

305

0.6

30

≥90

HFCFC-1.6

1.6

114

268

1.4

30

≥90

HFCFC-2

2

96

433

1.5

30

≥90

HFCFC-3

3

112

445

1.9

30

≥102

HFCFC-4.7

4.7

137

492

3.0

30

≥102

HFCFC-6.8

6.8

157

528

3.8

30

≥≥102

HFCFC-9

9

174

558

4.9

30

≥102

HFCFC-12

12

205

565

7.4

30

≥102


Carbon Fiber Breathing Air Cylinder 2L, 3L, 6.8L, 9L, 12L, Air Breathing Apparatus Cylinders, Air Breathing Apparatus SCBA Cylinder, Carbon Fiber Cylinder for breathing system.


Specs:

-Water volume: 1.0Liter to 12Liter;

-Outer diameter: 85mm to 208mm;

-Working pressure 200bar/300bar;

-Cylinder life-span: 15years;

-Aluminium lined and carbon fiber fully wrapped.


*Advantages: Safe, lightweight, corrosion-resistant, Superior strength, Durable design, perfect treatment for surface interior and exterior.


*Applications: Firefighting, pit rescue and other life support system.

Should you have any questions or some more info needed on our gas cylinders & related gas items, just pls feel free to contact us! ( E-mail : info@jshoofar.com ).
