fully wrapped high pressure carbon fiber cylinder 0.5-12L 4500psi 300bar Respiration Breathing Apparatus for firefighting-Product Center-CHANGZHOU HOOFAR INDUSTRIAL CO.,LTD-

fully wrapped high pressure carbon fiber cylinder0.5-12L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder

Name:	fully wrapped high pressure carbon fiber cylinder0.5-12L 4500psi 300bar Respiration Breathing Cylinder/Latest diving cylinder
Water volume:	0.5L-12L
Outer diameter:	85mm-208mm
Working pressure:	300bar
Test pressure:	500bar
Cylinder life-span:	15years
Material:	Aluminium lined and carbon fiber fully wrapped
Certificate:	CE
Standard:	EN1225
MOQ:	15PCS
Terms of Payment:	T/T,L/C or Western Union
Delivery Time:	20 days after payment
Port of Lading:	Shanghai or Ningbo

Product Description

Type	Volume （litre)	Outer Diameter (mm)	Length (mm)	Weight (kg)	Working Pressure (Mpa)	Breaking Pressure (Mpa)
HFCFC-0.5	0.5	60	305	0.6	30	≥90
HFCFC-1.6	1.6	114	268	1.4	30	≥90
HFCFC-2	2	96	433	1.5	30	≥90
HFCFC-3	3	112	445	1.9	30	≥102
HFCFC-4.7	4.7	137	492	3.0	30	≥102
HFCFC-6.8	6.8	157	528	3.8	30	≥≥102
HFCFC-9	9	174	558	4.9	30	≥102
HFCFC-12	12	205	565	7.4	30	≥102

Carbon Fiber Breathing Air Cylinder 2L, 3L, 6.8L, 9L, 12L, Air Breathing Apparatus Cylinders, Air Breathing Apparatus SCBA Cylinder, Carbon Fiber Cylinder for breathing system.

Specs:

-Water volume: 1.0Liter to 12Liter;

-Outer diameter: 85mm to 208mm;

-Working pressure 200bar/300bar;

-Cylinder life-span: 15years;

-Aluminium lined and carbon fiber fully wrapped.

*Advantages: Safe, lightweight, corrosion-resistant, Superior strength, Durable design, perfect treatment for surface interior and exterior.

*Applications: Firefighting, pit rescue and other life support system.

Should you have any questions or some more info needed on our gas cylinders & related gas items, just pls feel free to contact us! (Mob: +86-18118026813 or E-mail : info@jshoofar.com ).
