2019 New Seamless Aluminum Portable Carbon Fiber Scuba Tank-Product Center-CHANGZHOU HOOFAR INDUSTRIAL CO.,LTD-

300 Bar 4500 psi Fully Wrapped Carbon Fiber tank

Name:	300 Bar 4500 psi Fully Wrapped Carbon Fiber tank
Working Pressure:	300bar
Test Pressure:	500bar
Water capacity:	2L-12L
Material:	Aluminum lined with compositive carbon fiber
Pressure:	High
Thread Size:	M18×1.5
Outside diamter:	109mm,139mm,157mm,etc
Certification:	CE&CCS
Application:	SCBA
Service Time:	15years
Use:	filling air
MOQ:	15PCS
Terms of payment:	T/T,L/C,Western Union

Product Description

Type	Volume （litre)	Outer Diameter (mm)	Length (mm)	Weight (kg)	Working Pressure (Mpa)	Breaking Pressure (Mpa)
HFCFC-0.5	0.5	60	305	0.6	30	≥90
HFCFC-1.6	1.6	114	268	1.4	30	≥90
HFCFC-2	2	96	433	1.5	30	≥90
HFCFC-3	3	112	445	1.9	30	≥102
HFCFC-4.7	4.7	137	492	3.0	30	≥102
HFCFC-6.8	6.8	157	528	3.8	30	≥≥102
HFCFC-9	9	174	558	4.9	30	≥102
HFCFC-12	12	205	565	7.4	30	≥102

Structure: Aluminium lined and carbon fiber fully wrapped.

Advantage: * The highest standard for safety.

* Ultra lightweight, superior strength, durable design.

* Perfect treatment for surface interior and exterior to reach corrosion-free.

Application: Air Storage Tank for PCP guns, firefighting, pit rescue and other life support.

Standard: GB28053, EN12245

Others: Color, thread,valve and fittings upon request.

Should you have any questions or some more info needed on our gas cylinders & related gas items, just pls feel free to contact us! (Mob: +86-18118026813,E-mail:info@jshoofar.com ).
