Full set 30Mpa /300BAR 6.8L Carbon Fiber Cylinder for breathing storage

Name:	Full set 30Mpa /300BAR 6.8L Carbon Fiber Cylinder for breathing storage
Material:	Composite Material
Use:	Storage Air
Pressure:	300 bar
water capacity:	6.8L
outside diameter:	105mm
cylinder height:	430mm
cylinder weight:	3.9 kg
working pressure:	300bar
test pressure:	450bar
cylinder thread:	M181.5
service time:	15years
Standard:	EN12245
Certification:	CE

Product Description

Full set of 30Mpa 6.8L Carbon Fiber Cylinders

Type	Volume （litre)	Outer Diameter (mm)	Length (mm)	Weight (kg)	Working Pressure (Mpa)	Breaking Pressure (Mpa)
HFCFC-0.5	0.5	60	305	0.6	30	≥90
HFCFC-1.6	1.6	114	268	1.4	30	≥90
HFCFC-2	2	96	433	1.5	30	≥90
HFCFC-3	3	112	445	1.9	30	≥102
HFCFC-4.7	4.7	137	492	3.0	30	≥102
HFCFC-6.8	6.8	157	528	3.8	30	≥≥102
HFCFC-9	9	174	558	4.9	30	≥102
HFCFC-12	12	205	565	7.4	30	≥102

Product Description

As SCBA and life support cylinders feature aluminum alloy liner with thin wall and full-wrapped composite material exterior with carbon fiber and glass fiber with are suitable for Paintball Refil, SCBA, oxygen respirator, fire extinguisher, medical aid and emergency, as well as for use in automobile, space industry, etc.

Characteristics & Features:

1. Light weight: Up to 30 percent lighter than comparable steel cylinders;

2. Outer layer with full-wrapped superior glass fiber features creep resistance, shock resistance and corrosion resistance, etc.;

3. High pressure resistance;

4. Leakage first before explosion;

Company Information:

Dear My Friend,

So glad that you're interested in our products, We're professional manufacturer of all kinds of hunting equipments( carbon fiber cylinders, rifle scopes, air compressor and some related accessories ,etc ,)

If there's any more details you want to know, please feel free contact us. (E-mail : info@jshoofar.com )
